Plan No. 2994

Two Story

$1,795.00

2656 sqft • 3–5 bed • 3.5 bath

A wrap-around front veranda, stone accents and a double garage give this 2,656 sq. ft. two storey plenty of curb appeal, and a full-width covered deck runs across the back with a balcony above it. The main floor opens into one long space where the kitchen, with its island and eating bar, flows into the nook and a great room with a fireplace between built-in shelves. A pantry and desk sit just off the kitchen, while the dining room has French doors out to the veranda. From the garage, a mud room with a closet and a lav keeps the main floor tidy, and the laundry is tucked behind the kitchen. Upstairs, the master has two walk-in closets, a door to the balcony and an ensuite with a jet tub and a separate shower. Two more bedrooms share a full bath, and a large bonus room plus a 324 sq. ft. lower bonus room over the garage give room to grow. The optional basement adds two bedrooms, a bath and a family room with a fireplace.

Purchase options are not configured for this plan yet.

General specifications

Total living area
2,656 sq.ft.
1st level
1,217 sq.ft.
2nd level
1,439 sq.ft.
Stories
2
Walk out basement
No
Width
51'0"
Depth
46'0"
Ceiling style
Flat
Exterior wall
2x6
Foundation type included in the plan
Standard Concrete 8FT

Room breakdown

Bedroom(s)
3–5
Convertible (max bedrooms)
5
Full baths
3
Half baths
1
Garage type
Two-car garage (26'0" × 24'11")
Bonus room over garage
Yes

Main Floor

RoomsSizesDetails
Kitchen9'-6" x 16'-0"Island
Great room21'-0" x 15'-8"fireplace
Nook12'-0" x 13'-8"—
Mud room7'-8" x 8'-10"—
Dining room11'-4" x 9'-6"Formal Dining Room
Garage26'-0" x 24'-10"2 car
Bathroom—2-piece
Laundry room—Main Floor Laundry

Second Floor

RoomsSizesDetails
Bedroom No.212'-0" x 11'-4"—
Bedroom No.311'-0" x 13'-6"—
Master bedroom14'-4" x 15'-8"—
Ensuite—4-piece
Bathroom—3-piece

Basement

RoomsSizesDetails
Bedroom9'-10" x 10'-0"—
Bathroom—3-piece
Mechanical room10'-6" x 14'-10"—
Bedroom14'-0" x 13'-0"Irregular shape
Storage6'-4" x 7'-2"—
Family room20'-0" x 15'-4"—
