Plan No. 4107
$1,395.00
Two mirror-image homes share one roofline in this 3,030 sq. ft. side-by-side duplex, each unit offering 1,515 sq. ft. over two floors. Both front doors sit tucked under a shared porch roof between the gables, opening beside a flex room that suits an office, playroom or guest space. Toward the back, each unit opens up into a kitchen with an island and eating bar, a dining area and a living room with a door to its own rear deck, plus a pantry and powder room. Upstairs are three bedrooms, a main bath, a laundry closet and a master suite with a walk-in closet and a double-vanity ensuite. The optional basement plan finishes each unit with a family room, two more bedrooms and a third full bath.
General specifications
- Total living area
- 1,515 sq.ft.
- 1st level
- 796 sq.ft.
- 2nd level
- 719 sq.ft.
- Stories
- 2
- Walk out basement
- No
- Width
- 40'0"
- Depth
- 44'0"
- Exterior wall
- 2x6
- Foundation type included in the plan
- Standard Concrete 9FT
Room breakdown
- Bedroom(s)
- 3–5
- Convertible (max bedrooms)
- 5
- Full baths
- 3
- Half baths
- 1
- Garage type
- No Garage
- Bonus room over garage
- No
Main Floor
| Rooms | Sizes | Details |
|---|---|---|
| Kitchen | 8'-6" x 10'-8" | Island |
| Living room | 13'-0" x 12'-4" | 9' ceiling |
| Dining room | 10'-6" x 12'-2" | 9' Ceiling |
| Bathroom | — | 2-piece |
| Flex Room | 12'-0" x 10'-4" | Den, Office, Playroom |
Second Floor
| Rooms | Sizes | Details |
|---|---|---|
| Master bedroom | 13'-0" x 12'-8" | Ensuite, Walk-in Pantry |
| Bedroom No.2 | 9'-6" x 9'-8" | — |
| Bedroom No.3 | 9'-8" x 10'-4" | — |
| Laundry room | — | Laundry Closet |
| Bathroom | — | 3-piece |
| Ensuite | — | 3-piece |
| Walk-in closet | — | — |
Basement
| Rooms | Sizes | Details |
|---|---|---|
| Bathroom | 11'-0" x 9'-10" | 3-piece |
| Bedroom | 12'-4" x 8'-6" | — |
| Bedroom | — | — |
| Mechanical room | — | — |
| Family room | 13'-0" x 15'-2" | 9' ceiling |
